EPM570T100I5N Description

The EPM570T100I5N is a member of the MAX® 10 family, which is known for offering a low-cost, single-chip solution that integrates FPGA fabric with embedded memory and non-volatile flash memory. The EPM570T100I5N is designed for applications that require both logic flexibility and deterministic performance, combined with power efficiency. It includes a variety of I/O options and is packaged in a 100-pin form factor. The EPM570T100I5N is an ideal choice for applications requiring fast logic implementation and minimal system complexity.

EPM570T100I5N Features

FPGA Fabric: 570 Logic Elements (LEs) for versatile logic configuration.

Non-Volatile Flash Memory: Embedded flash for configuration storage, enabling instant-on functionality without external configuration memory.

High-Speed I/O: Supports up to 16 I/O standards including LVTTL, LVCMOS, and others for seamless integration.

Low Power Consumption: Optimized for power-sensitive applications with low static and dynamic power requirements.

Flexible Configuration: Built-in configuration via JTAG and other interfaces, providing flexibility during development and deployment.

Embedded Memory: Includes dedicated on-chip memory blocks, supporting efficient design without external memory components.

Temperature Range: Designed for operation over a wide temperature range to meet the demands of industrial and automotive environments.

Package: Available in a 100-pin TQFP package, providing a balance between I/O availability and size.

Integrated PLLs: For clock management and clock data recovery functions.

EPM570T100I5N Applications

Industrial Automation: The EPM570T100I5N is ideal for control systems, sensor interfacing, and real-time data processing in industrial environments.

Automotive Systems: Used in automotive electronics for systems such as ADAS (Advanced Driver Assistance Systems), infotainment, and control modules.

Embedded Systems: Suitable for embedded logic systems, providing a small form factor with high flexibility.

Data Communication: Provides signal processing capabilities for high-speed communication protocols and data transfer systems.

Consumer Electronics: Implemented in devices such as digital cameras, home automation systems, and custom electronics.

Test and Measurement: Useful for custom test equipment that requires adaptable logic and processing capabilities.

EPM570T100I5N Pinout(Key Highlight)

JTAG Programming Pins:

TDI (Pin 44) – JTAG Test Data Input

TDO (Pin 45) – JTAG Test Data Output

TCK (Pin 46) – JTAG Test Clock

TMS (Pin 47) – JTAG Mode Select

Power Supply Pins:

VCCINT (Pins 85, 90) – Core Power (1.8V)

VCCIO (Pins 10, 20, 40, 60, 75, 100) – I/O Power Supply (1.8V – 3.3V)

GND (Multiple Pins) – Ground

Clock Inputs:

CLK0 (Pin 30)

CLK1 (Pin 55)

CLK2 (Pin 70)

User I/O Pins:

76 configurable I/O pins (IO1 – IO76) for versatile applications

EPM570T100I5N CAD Model

Symbol

Footprint

3D Model

EPM570T100I5N Alternatives

Intel Cyclone® IV E FPGA – A lower-cost, lower-power alternative for simpler applications.

Xilinx Spartan®-6 FPGA – A competitor FPGA with similar logic density and flexibility.

Lattice Semiconductor iCE40™ FPGA – Offers low power and small form factor for ultra-compact applications.

Microchip PolarFire® FPGA – A higher-end alternative with lower power consumption and more extensive I/O capabilities.

Xilinx Artix®-7 FPGA – A more feature-rich alternative, suitable for more demanding applications.

EPM570T100I5N Advantages

The EPM570T100I5N is an excellent choice for applications needing a low-power, non-volatile CPLD with high logic density and fast configuration times. Compared to alternatives, it offers:

More logic resources in a small package

Lower power consumption than legacy CPLDs

Instant-on capability without external configuration memory

Reliable operation in industrial environments

Competitive pricing compared to low-end FPGAs

This makes it ideal for industrial control, automotive electronics, embedded systems, and communication applications where cost, reliability, and power efficiency are key factors.

EPM570T100I5N Manufacturer

Intel Corporation is a leading global semiconductor company known for developing high-performance processors, FPGAs, and advanced computing technologies. Founded in 1968 and headquartered in Santa Clara, California, Intel pioneered x86 architecture and continues to innovate in AI, data centers, and IoT. It provides cutting-edge solutions for PCs, cloud computing, and embedded systems, driving technological advancements worldwide.

EPM570T100I5N FAQs

What is the maximum clock frequency of the EPM570T100I5N?

The EPM570T100I5N can operate at a maximum clock frequency of 200 MHz, depending on the design and the complexity of the implemented logic.

How is the embedded flash memory utilized in the EPM570T100I5N?

The embedded flash memory in the EPM570T100I5N is primarily used for storing configuration data. This allows the device to retain its configuration after power cycles, ensuring "instant-on" functionality.

What is the power consumption of the EPM570T100I5N during typical operation?

The typical power consumption during standard operation is around 150 mW to 300 mW, depending on the logic complexity and I/O load.

Can the EPM570T100I5N be used in applications that require high-temperature operation?

Yes, the EPM570T100I5N is rated for industrial-grade temperature ranges, typically from -40°C to 100°C, making it suitable for use in harsh environments.

What are the primary benefits of using a MAX® 10 FPGA like the EPM570T100I5N in embedded systems?

The MAX® 10 FPGA offers low power consumption, integrated non-volatile flash memory, and an easily customizable logic fabric, making it ideal for embedded systems that require flexibility, low cost, and reduced system complexity. It also supports fast development and time-to-market with its integrated configuration memory and I/O options.
